Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-mac * cable cm-tcs-max-size

Purpose

Configures the cable-mac maximum size for TCS entries.

Default Access Level

Command Syntax

configure interface cable-mac <mac> cable cm-tc-max-size <1-8>

configure interface cable-mac <mac> cable cm-tc-max-size [<1-8>] no

Supplemental

Information

To disable, use the no option.

Parameters

<1-8>

Maximum limit of TCS entries.

Default Chapter7
