Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

quit

Purpose

If you are in interface configure mode quit will return you to global configuration mode. If you are in user mode, quit closes your

CLI session. If you are in privileged mode, you will need to type disable to return to user mode. If you type quit from privileged

mode, you will terminate the CLI session.

Default Access Level

Command Syntax

quit [all]

Supplemental

Information

N/A

Parameters

[all]

Exits all intermediate modes.

Related Commands

exit (page 2588)

logout (page 2595)
