Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-mac * cable downstream-bonding-group dynamic reseq-

wait-time

Purpose

Configures the resequence wait time for dynamic DSIDs in the specified cable-mac.

Default Access Level

Command Syntax

configure interface cable-mac <mac> cable downstream-bonding-group dynamic reseq-wait-time <int>

configure interface cable-mac <mac> cable downstream-bonding-group dynamic reseq-wait-time <int> no

Supplemental

Information

To disable, use the no option.

Parameters

<mac>

The MAC identifier. Valid numbers are 0-415.

<int>

Resequence wait time in hundredMicroseconds (1-180 or 255).
