Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show cable noise

Purpose

Displays cable noise information.

Default Access Level

Command Syntax

show cable noise [detail] [snr-below <1-55>] [cable-mac <mac>] [cable-upstream <word>]

Supplemental

Information

N/A

Parameters

[detail]

Displays information in detail format.

[snr-below <1-55>]

Displays cable noise for any upstream below specified SNR excluding 0.

[cable-mac

<slot/port>]

MAC identifier (0-415 or slot/mac).

[cable-upstream

<word>]

Slot/upstream port number.
