configure audit sequence * enable

Purpose

Enables specified audit sequences.

Default Access Level

Command Syntax

configure audit sequence [<name>] enable

configure audit sequence [<name>] enable no

Supplemental

Information

If no audit sequence is specified, then all cards in service will be enabled.

To disable, use the no option.

Parameters

[<name>]

Audit Sequence Name. Valid names are:

AuditCMMac

AuditCMQos

IpFilter

AuditCMBpi

CAMSparing

CAMManager

PersistentStore

PacketCableGates
