Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure logging monitor

Purpose

Sends the system logging messages of a given priority to the telnet session by setting the logging level.

Default Access Level

Command Syntax

configure logging monitor <level>

configure logging monitor <level> no

Supplemental

Information

The output will continue to be routed to the telnet session until either the logging to the monitor is disabled or the telnet session is

disconnected.

To disable delivery of all notifications to the telnet session, use the no option.

Parameters

<level>

Values of priority level are:

1 = emergency 5 = warning

2 = alert 6 = notice

3 = critical 7 = informational

4 = error 8 = debug
