Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure audit sequence * run-now

Purpose

Enables specific audit sequences to run immediately.

Default Access Level

Command Syntax

configure audit sequence [<name>] run-now

Supplemental

Information

N/A

Parameters

[<name>]

Audit Sequence Name. Valid names are:

AuditCMMac

AuditCMQos

IpFilter

AuditCMBpi

CAMSparing

CAMManager

PersistentStore

PacketCableGates
