Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure cable modem format

Purpose

Configures a customized "show cable modem format".

Default Access Level

Command Syntax

configure cable modem format <word>

configure cable modem format <word> no
