Chapter 46: Command Line Descriptions
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 1263
configure cable dsg tunnel * classifier
Purpose
This command provisions a classifier and associates the classifier with a DSG tunnel.
Default Access Level
15
Command Syntax
configure cable dsg tunnel <0-4294967295> classifier <1-65535> [priority <0-255>] [source-network
<domain-name | a.b.c.d [/prefix]>] [dest-ip <a.b.c.d>] [dest-port-range <0-65535> - <0-65535>]
[include-in-dcd]
configure cable dsg tunnel <0-4294967295> classifier <1-65535> [priority <0-255>] [source-network
<domain-name | a.b.c.d [/prefix]>] [dest-ip <a.b.c.d>] [dest-port-range <0-65535> - <0-65535>]
[include-in-dcd] no
Supplemental
Information
To delete a classifier for a tunnel, use the no option.
Parameters
<0-4294967295>
Unsigned integer that represents the tunnel to be displayed. Valid numbers are any unsigned integer values.
<1-65535>
DSG tunnel group to which this DSG tunnel belongs.
[priority <0-255>]
Priority of the classifier.
[source-network <domain-
name>|<a.b.c.d [/prefix]>]
The source-network domain name or IP address.
[dest-ip <a.b.c.d>]
The destination IP address to be matched.
[dest-port-range <0-65535> - <0-
65535>]
The inclusive lower bound of the transport layer port range along with the inclusive upper bound of the transport
layer port range that is to be matched. Valid range is {<0-65535> - <0-65535>} and must be in the format of ‘start -
end’.
[include-in-dcd]
Includes the classifier in the DCD message. The default is not to include the classifier in the DCD message.
