Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure ipv6 nd state non-present global-max-rate

Purpose

Configures the Neighbor Discovery state not-present limits.

Default Access Level

Command Syntax

configure ipv6 nd state not-present global-max-rate <0-65535>

configure ipv6 nd state not-present global-max-rate[<0-65535>] no

Supplemental

Information

To reset, use the no option.

Parameters

<0-65535>

Maximum ICMP transmit rate for all ND in packets/second for ICMPs.
