Multicast Destination IP to non-RFC1112 DSG Tunnel MAC
The following script configures a DSG tunnel that has a destination IP address that corresponds to a destination MAC
address that does not comply with RFC1112. The table below is a summary of that DSG tunnel:
Table 81. Summary of DSG Tunnel with Multicast DIP to Non-compliant DMAC Address
Type
Name
Value
23
Downstream Packet Classification Encoding
-
23.2
Classifier Identifier
1
23.5
Classifier Priority
1
23.9
IP Packet Classification Encodings
-
23.9.3
Source IP Address
10.100.10.1
23.9.4
Source IP Mask
255.255.255.255
23.9.5
Destination IP Address
230.1.1.1
50
DSG Rule
-
50.2
DSG Rule Priority
1
50.4.2
DSG Well-Known MAC Address
00:00:CA:01:01:0
1
50.5
DSG Tunnel Address
00:11:22:33:44:5
5
50.6
DSG Classifier Identifier
1
