Arris C4C - Show Cable Multicast Db

To Next Page

To Previous Page

Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show cable multicast db

Purpose

Displays information for multicast replication on the specified cable-mac.

Default Access Level

Command Syntax

show cable multicast db [cable-mac <0-415>] [grp-ip-addr <ipv4 | ipv6>] [src-ip-addr <IPv4 | IPv6>]

[session-type {igmp | pcmm | dsg}]

Supplemental

Information

N/A

Parameters

[cable-mac <0-415>]

Filters on the cable-mac

[grp-ip-addr <ipv4 |

ipv6>]

Group IP Address either IPv4 or IPv6.

[src-ip-addr <ipv4 | ipv6>]

Source IP Address either IPv4 or IPv6.

[session-type {igmp |

pcmm | dsg}]

Defines the session type as either IGMP, PCMM or DSG.
