Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

ping

Purpose

The ping (Packet Internet Groper) command is a common method of troubleshooting the accessibility of devices.

Default Access Level

Command Syntax

ping <ip address> [source <ip addr>| hostname] [repeat-count <int>] [timeout <int>] [size <int>] [tos

<int>] [ttl <int>] [payload <payload pattern>] [validate] [dont-fragment] [mgmt]
