Upstream Receive Power Levels
Upstream channels connected to a single physical connector may vary in channel width and power levels as long as the
variance falls within a user-configured power level group. The tables below describe the three power level groups. All of
the power levels for all of the channels connected to a single physical connector must fall within the same table.
Table 35. US Receiver Power Level Group 1
1.6 MHz
3.2 MHz
6.4 MHz
-13
-10
-7
-12
-9
-6
-11
-9
-5
-10
-8
-4
-9
-7
-3
-8
-6
-2
Note: All upstream Rx (receive) values are measured in dBmV. Power after attenuation may vary slightly from one CAM to
another. Power Level Group 1 supports a total input power of 29 dBmV.
Table 36. US Receiver Power Level Group 2
1.6 MHz
3.2 MHz
6.4 MHz
-7
-4
-1
-6
-3
0
-5
-2
1
-4
-1
2
