Multicast Destination IP to RFC1112 DSG Tunnel MAC
The following script configures a DSG tunnel that has a destination IP address that directly corresponds to an RFC1112-
compliant destination MAC address.
This example shows how to configure a DSG tunnel with the following rule and classifier:
Table 80. DSG Tunnel with Multicast IP Address
Type
Name
Value
23
Downstream Packet Classification Encoding
-
23.2
Classifier Identifier
1
23.5
Classifier Priority
1
23.9
IP Packet Classification Encodings
-
23.9.3
Source IP Address
10.100.10.1
23.9.4
Source IP Mask
255.255.255.255
23.9.5
Destination IP Address
230.1.1.1
50
DSG Rule
-
50.2
DSG Rule Priority
1
50.4.2
DSG Well-Known MAC Address
00:00:CA:01:01:01
50.5
DSG Tunnel Address
01:00:5E:01:01:01
50.6
DSG Classifier Identifier
1
#----------------------------------------------------
# start Multicast IP to Associated DMAC script
#----------------------------------------------------
#
# DSG tunnel provisioning
#
#----------------------------------------------------
# inbound network side filtering
