Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show ip interface * gigabitethernet

Purpose

Displays the gigabitethernet interface information for the client modules.

Default Access Level

Command Syntax

show ip interface [brief] gigabitethernet <slot>/<port>

Supplemental

Information

N/A

Parameters

[brief]

Displays the output in brief format

RCM slot number/gigabitEthernet port number.

Valid range for the C4 CMTS is <17-18>/<0-9>

Valid range for the C4c CMTS is <17>/<0-9>
