Chapter 7: Router Control Module (RCM)
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 215
Note: The SFP and XFP modules are compliant with the SFP and XFP MSAs, respectively; however, only the approved
1000 Base-TX modules are guaranteed to operate correctly in the 10/100/1000 mode of operation. Contact your ARRIS
Sales or Technical Representative for more information on approved modules.
See the following table for the IEEE specified minimum length limits for the various modules and fiber types.
Table 22. Overview of IEEE SFP and XFP Types and Specifications
Connection Type
Wavelength
Fiber Type
Max.
Distance
SFP GbE Fiber Modules
1000Base-SX
850nm
62.5/125 multi-mode, 160MHz
62.5/125 multi-mode, 200MHz
50/125 multi-mode, 400MHz
50/125 multi-mode, 500MHz
220m
275m
500m
550m
1000Base-LX10
1310nm
62.5/125 multi-mode, 500MHz
50/125 multi-mode, 400MHz
50/125 multi-mode, 500MHz
9/125 single mode
550m
550m
550m
5km
1000Base-EX
1310nm
9/125 single mode
10km
1000Base-ZX
(not IEEE spec)
1550nm
9/125 single mode
70km
XFP 10GbE Fiber Modules
10GBase-SR
850nm
62.5/125 multi-mode, 160MHz
62.5/125 multi-mode, 200MHz
50/125 multi-mode, 400MHz
50/125 multi-mode, 500MHz
50/125 multi-mode, 2000MHz
26m
33m
66m
82m
300m
