Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure packetcable voice-limits allowed-normal

Purpose

Defines the maximum percent of the downstream and upstream channel bandwidth reserved for normal voice.

Default Access Level

Command Syntax

configure packetcable voice-limits allowed-normal <percent> [downstream | upstream]

Supplemental

Information

Rules/Limits on Percentage Values:

Maximum range 0-90

allowed-total >=allowed normal

allowed-total >=reserved-emergency

allowed-total >=reserved normal + reserved-emergency

Parameters

The percentage allowed for normal voice use. Valid range is 0 to 90. See table above.

[downstream|upstream]

Direction of channel bandwidth.
