Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-upstream * cable channel-width

Purpose

Configures the channel width for the specified upstream.

Default Access Level

Command Syntax

configure interface cable-upstream <slot/ch[.0]> cable channel-width <width-hz>

Supplemental

Information

N/A

Parameters

The upstream slot/channel[.logical channel]. It will assume lc=0 if needed and not supplied.

<width-hz>

Valid values for channel width in Hertz (Hz) are:

200000 Hz = 150,000 symbols/sec

400000 Hz = 320,000 symbols/sec

800000 Hz = 640,000 symbols/sec

1600000 Hz =1,280,000 symbols/sec

3200000 Hz = 2,560,000 symbols/sec

6400000 Hz = 5,120,00000 symbols/sec

Related Commands

show interface cable (page 2780)

show interface cable-upstream (page 2810)
