Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-upstream * cable docsis-mode

Purpose

.Configures the specified upstream DOCSIS-mode.

Default Access Level

Command Syntax

configure interface cable-upstream <slot/ch[.0]> cable docsis-mode <type>

Supplemental

Information

N/A

Parameters

The upstream slot/channel[.logical channel]. It will assume lc=0 if needed and not supplied.

<type>

Valid values for DOCSIS-modes are:

 tdma

 atdma

 scdma

 adma-atdma

Related Commands

show interface cable-upstream (page 2810)
