Chapter 46: Command Line Descriptions
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 1876
configure interface link-aggregate * ip rip authentication key
Sets the authentication key.
configure interface link-aggregate <0-9[.0-254]> ip rip authentication key <keychain1>
configure interface link-aggregate <0-9[.0-254]> ip rip authentication key [<keychain1>] no
Every RIP message sent on this interface will contain this key and every incoming message received will be validated based on it
having this key.
Note: All commands that include key-chains required that the key-chain already exists before the command is executed. In addition,
the key-chain should not be deleted until after the command(s) that reference it have been reset with the "no" command.
To reset the authentication key, use the no option.
Parameters
LAG identifier <lag[sub interface]>
A 1-16 character text string used for authentication.
