Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show ip interface * tengigabitethernet

Purpose

Displays the tengigabitethernet interface information for the client modules.

Default Access Level

Command Syntax

show ip interface [brief] tengigabitethernet <slot>/<port>

Supplemental

Information

N/A

Parameters

[brief]

Displays the output in brief format

RCM slot number/gigabitEthernet port number.

Valid range for the C4 CMTS is <17-18>/<10>

Valid range for the C4c CMTS is <17>/<10>
