Arris C4C - Show Running-Config Interface Cable-Mac

To Next Page

To Previous Page

Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show running-config interface cable-mac

Purpose

Displays the parameters for the cable-mac interface specified.

Default Access Level

Command Syntax

show running-config interface cable-mac <mac> [verbose] [linenum] [full]

Supplemental

Information

N/A

Parameters

<mac>

The MAC identifier. Valid numbers are 0-415.

[verbose]

Displays the output with ‘configure’ on each line.

[linenum]

Enumerates each line with its line number in the output.

[full]

Displays all configuration values, including default values.
