Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-mac * cable upstream-bonding-group * attribute-mask

value

Purpose

Configures the attribute mask encoding for the bonding group.

Default Access Level

Command Syntax

configure interface cable-mac <mac> cable upstream-bonding-group <int> attribute-mask value <value>

configure interface cable-mac <mac> cable upstream-bonding-group <int> attribute-mask value [<value>] no

Supplemental

Information

To restore the default attribute mask value of 0x80000000, use the no option.

Parameters

<mac>

The MAC identifier. Valid numbers are 0-415.

<int>

Static bonding group identifier

<value>

A hex string that must be greater than the default of 0x80000000

Related Commands

show cable bonding-group-status (page 2637)
