Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-downstream * cable attribute-mask value

Purpose

Configures attributes for the specified channel for channel assignment.

Default Access Level

Command Syntax

configure interface cable-downstream <slot/port> cable attribute-mask value <word>

Supplemental

Information

N/A

Parameters

<slot>

The chassis slot in which the targeted downstream Cable Access Module resides. Valid range for the C4 CMTS is 0-15; valid range for

the C4c CMTS is 10-15.

<port>

The downstream port.

<word>

Attribute bits of the channel.

Related Commands

show interface cable
