Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure ipv6 nd state searching rate-limit

Purpose

Configures the maximum Neighbor Discovery state searching limits.

Default Access

Level

Command Syntax

configure ipv6 nd state searching rate-limit <100-86400000>

configure ipv6 nd state searching rate-limit [<100-86400000>] no

Supplemental

Information

To reset, use the no option.

Parameters

<100-86400000>

Minimum time, in msec, between NDs.

Default Chapter7
