Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show netstat

Purpose

Displays the currently active network connections and statistics.

Default Access Level

Command Syntax

show netstat [slot <slot>] [routes] [stats] [interfaces]

Supplemental

Information

N/A

Parameters

[slot <0-20>]

The chassis slot in which the targeted module resides.

[routes]

Keyword to show the IP routing table

[stats]

Keyword to show all statistics for TCP, UDP, IP and ICMP

[interfaces]

Keyword to show the interface statistics
