Arris C4C - Configure Packetcable Voice-Limits Reserved-Emergency

To Next Page

To Previous Page

Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure packetcable voice-limits reserved-emergency

Purpose

Defines the minimum percent of the downstream and upstream channel bandwidth reserved for emergency voice.

Default Access Level

Command Syntax

configure packetcable voice-limits reserved-emergency <percent> [downstream | upstream]

Supplemental

Information

Rules/Limits on Percentage Values:

Maximum range 0-90

allowed-total >=reserved normal + reserved-emergency

allowed-emergency reserved-emergency

Parameters

The percentage reserved for emergency voice use. See table above.

[downstream|upstrea

Direction of channel bandwidth.
