Arris C4C - Configure Interface Gigabitethernet Speed

To Next Page

To Previous Page

Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface gigabitethernet * speed

Purpose

Sets the speed of the ethernet interface.

Default Access Level

Command Syntax

configure interface gigabitethernet <slot/port> speed [100M | 1G | auto]

Supplemental

Information

N/A

Parameters

RCM slot number/gigabitEthernet port number.

Valid range for the C4 CMTS is <17-18>/<0-9>

Valid range for the C4c CMTS is <17>/<0-9>

[100M]

Speed set to 100 mbps

[1G]

Speed set to 1 Gbps (1000 mbps)

[auto]

Speed set by negotiation, or is dependent on hardware.
