Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show temperature slot

Purpose

Displays the temperature of each equipped chassis slot.

Default Access Level

Command Syntax

show temperature slot <0-20>

Supplemental

Information

The temperature is monitored at approximately 90-second intervals. Should a slot’s temperature fall below 20 degrees Celsius

or exceed 70 degrees Celsius, a card TempOutOfRangeNotification SNMP trap is generated. Should a slot’s temperature exceed

90 degrees Celsius, the card will power down and a card TempOverHeatNotification SNMP trap is generated. Use the optional

slot parameter if you only need status for a specific module.

Parameters

[slot <0-20>]

The chassis slot in which the targeted module resides.
