SCM/SCM II Ethernet Interfaces
The Ethernet connection must be at least a 10 baseT and half duplex connection. There is only one port but it can be
reached through either one of two RJ45 connectors one in front and one in back. Only one of these maintenance
Ethernet interfaces on the SCM/SCM IIs may be used at a time.
SCM 3 Ethernet Interfaces
While the SCM 3 Ethernet interfaces are in the same location as those of the SCM and SCM II, the implementation is
different. As on the prior SCMs, the Link/Activity LED’s reside on the SCM 3 front panel. For the SCM 3, however, these
Link/Activity LEDs only reflect the status of the front panel ethernet interface. The SCM PIC-resident ethernet interface
does not have Link/Activity LEDs.
The software will support:
One of the SCM 3 physical ethernet interfaces as active/operational at a time and they will share the SCM MAC address
between them.
The SCM 3 will provide the ability to select either the front or the rear Ethernet port as the active/operational port.
The selection of the (front/rear) port will happen at boot time using the same "menu" as the Ethernet port IP address,
subnet, and gateway.
The setting of the active/operational Ethernet port (front/rear) is printed to the console port during boot, stored in the
SCM PIC (with fan controller), and is persistent across reboots.
A single Ethernet port directional setting applies to both SCM 3s if the system is a duplex system.
For newly manufactured SCM PICs (with fan controllers), the default orientation will have the rear Ethernet port being
active/operational.
Legacy/existing SCM PICs will also have the default orientation of the rear Ethernet port active/operational.
Slots 19 and 20 are reserved for the SCM cards on the C4 CMTS and Slot 19 for the C4c CMTS.
Removing the SCM in a simplex configuration (one SCM) will shut down the CMTS. The SCM provides the ON/OFF power
control for all client modules (CAMs) in the CMTS. If the simplex SCM is removed, then the power converters on all client
modules are shut off.
