Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure router bgp * address-family ipv4 neighbor * maximum-prefix * warning-

only

Purpose

Configures the neighbor table.

Default Access Level

Command Syntax

configure router bgp [<int>] address-family ipv4 neighbor <a.b.c.d> maximum-prefix <int> warning-only

configure router bgp [<int>] address-family ipv4 neighbor <a.b.c.d> maximum-prefix [<int>] warning-only

Supplemental

Information

To disable, use the no option.

Parameters

[<int>]

Autonomous System (AS) number. Valid range is 1-65535

<a.b.c.d>

Neighbor IP address.
