Arris C4C - Show Interface Cable-Mac Mac-Scheduler

Chapter 46: Command Line Descriptions
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 2805
show interface cable-mac * mac-scheduler
Purpose
Displays the time-slot scheduling state and statistics.
Default Access Level
15
Command Syntax
show interface cable-mac <mac> mac-scheduler {interval <1-31536000>} {type <req | req-summary |
grants-pending | queues | flows | mslots | mslots-summary>} [detail]
Supplemental
Information
N/A
Parameters
<mac>
The MAC identifier. Valid numbers are 0-415.
[upstream <upstream port>]
The upstream port number. Valid range is 0-7
{interval <1-31536000>}
The time span in seconds to monitor changes in scheduler information.
{type <req | req-summary | grants-pending |
queues | flows | mslots | mslots-summary>}
The type of scheduler information to display
[detail]
Displays complete output at full precision.
