Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

[cm-ipv6 <ip addr>]

Filters on the CM IPv6 address

[cm-mac <mac

addr>]

Filters on the MAC address of the cable modem

[cpe-ip <ip addr>]

Filters on the IP address of the CPE under the cable modem

[cpe-ipv6 <word>]

Filters on the CPE IPv6 address under the cable modem

[cpe-mac <ip addr>]

Filters on the MAC address of the CPE under the cable modem

[max-ftime <0-

100000>]

Maximum latest flap-time in minutes.

[min-error <int>]

Minimum combined CRC and HCS error count

[min-fcount <0-

100000>]

Minimum flap count

[non-operational]

Filters on non-operational CMs

[offline]

Offline cable modems

[operational]

Filters on operational CMs

[registered]

All registered cable modems

[slot <number>]

Filters on the CAM slot number
