Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

[precedence <0-7>]

Match packets with given precedence value. Valid values are:

0 = routine - Match packets with routine precedence

1 = priority - Match packets with priority precedence

2 = immediate - Match packets with immediate precedence

3 = flash - Match packets with flash precedence

4 = flash-override - Match packets with flash override precedence

5 = critical - Match packets with critical precedence

6 = internet - Match packets with internetwork control precedence

7 = network - Match packets with network control precedence

[tos <0-15>]

Match packets with given TOS value

[fragments]

Check non-initial fragment
