Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

[login-

authentication]

Set authentication type to ‘login’

[enable-

authentication]

Allows the user to use the enable command to go into privileged mode.

[authorization

<word>]

Authorization method list name (up to 16 characters)

[connect <active |

local>

Active: The standby SCM console port is connected to the active SCM.

Local: The standby SCM console port is directly available.

Related Commands

configure pagination (page 2232)

terminal length (page 3057)

show running-config interface cable-downstream (page 3023)

Default Chapter7
