Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

em1x1mode-enable

Filter on CMs enabled for Energy Management 1x1 mode operation

em1x1mode-oper

Filter on CMs currently operating in Energy Management 1x1 mode

max-lines

Maximum number of CMs to display.

min-error

Filter on minimum combined CRC and HCS error count.

non-operational

Filter on non-operational CMs.

operational

Filter on operational CMs.

rogue

Filter on rogue CMs.

slot <slot>

Filter on CAM slot.

state <state>

Filter on SM state.

vendor <name>

Filter on CM vendor name.

The CMs can be displayed in various formats:
