ST SPC560P34 User Manual

RM0046 FlexCAN
Doc ID 16912 Rev 5 551/936
Rx 14 Mask (RX14MASK)
This register is provided for legacy support and for low cost MCUs that do not have the
individual masking per Message Buffer feature. For MCUs supporting individual masks per
MB, setting the BCC bit in the MCR causes the RX14MASK register to have no effect on the
module operation.
RX14MASK is used as an acceptance mask for the Identifier in Message Buffer 14. When
the FEN bit in the MCR is set (FIFO enabled), the RX14MASK also applies to element 6 of
the ID filter table. This register has the same structure as the Rx Global Mask Register. It
must be programmed while the module is in Freeze Mode, and must not be modified when
the module is transmitting or receiving frames.
Rx 15 Mask (RX15MASK)
This register is provided for legacy support and for low cost MCUs that do not have the
individual masking per Message Buffer feature. For MCUs supporting individual masks per
MB, setting the BCC bit in the MCR causes the RX15MASK register to have no effect on the
module operation.
Table 277. RXGMASK field description
Field Description
0–31
MI31–MI0
Mask Bits
For normal Rx MBs, the mask bits affect the ID filter programmed on the MB. For the Rx FIFO, the
mask bits affect all bits programmed in the filter table (ID, IDE, RTR).
0 The corresponding bit in the filter is “don’t care.”
1 The corresponding bit in the filter is checked against the one received.
Figure 269. Rx Buffer 14 Mask register (RX14MASK)
Address: Base + 0x0014 Access: User read/write
0123456789101112131415
R
MI31 MI30 MI29 MI28 MI27 MI26 MI25 MI24 MI23 MI22 MI21 MI20 MI19 MI18 MI17 MI16
W
Reset1111111111111111
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
MI15 MI14 MI13 MI12 MI11 MI10 MI9 MI8 MI7 MI6 MI5 MI4 MI3 MI2 MI1 MI0
W
Reset1111111111111111
Table 278. RX14MASK field description
Field Description
0–31
MI31–MI0
Mask Bits
For normal Rx MBs, the mask bits affect the ID filter programmed on the MB. For the Rx FIFO, the mask bits
affect all bits programmed in the filter table (ID, IDE, RTR).
0 The corresponding bit in the filter is “don’t care.”
1 The corresponding bit in the filter is checked against the one received.
