LIN Controller (LINFlex) RM0046
492/936 Doc ID 16912 Rev 5
LIN control register 1 (LINCR1)
0x0044 Identifier filter match index (IFMI) on page 21-514
0x0048 Identifier filter mode register (IFMR) on page 21-514
0x004C Identifier filter control register 0 (IFCR0) on page 21-516
0x0050 Identifier filter control register 1 (IFCR1) on page 21-517
0x0054 Identifier filter control register 2 (IFCR2) on page 21-517
0x0058 Identifier filter control register 3 (IFCR3) on page 21-517
0x005C Identifier filter control register 4 (IFCR4) on page 21-517
0x0060 Identifier filter control register 5 (IFCR5) on page 21-517
0x0064 Identifier filter control register 6 (IFCR6) on page 21-517
0x0068 Identifier filter control register 7 (IFCR7) on page 21-517
0x006C Identifier filter control register 8 (IFCR8) on page 21-517
0x0070 Identifier filter control register 9 (IFCR9) on page 21-517
0x0074 Identifier filter control register 10 (IFCR10) on page 21-517
0x0078 Identifier filter control register 11 (IFCR11) on page 21-517
0x007C Identifier filter control register 12 (IFCR12) on page 21-517
0x0080 Identifier filter control register 13 (IFCR13) on page 21-517
0x0084 Identifier filter control register 14 (IFCR14) on page 21-517
0x0088 Identifier filter control register 15 (IFCR15) on page 21-517
0x008C–0x000F Reserved
1. LSB: Least significant byte
2. MSB: Most significant byte
Table 233. LINFlex memory map (continued)
Address offset Register Location
Figure 235. LIN control register 1 (LINCR1)
Offset: 0x0000 Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
CCD CFD LASE AWUM MBL BF SFTM LBKM MME SBDT RBLM SLEEP INIT
W
Reset0000000010000010
