RM0046 eTimer
Doc ID 16912 Rev 5 707/936
Table 364. eTimer memory map
Offset from
eTIMER0_BASE
(FFE1_8000)
Register Location
eTimer Channel 0
0x0000 COMP1—Compare Register 1 on page 26-710
0x0002 COMP2—Compare Register 2 on page 26-711
0x0004 CAPT1—Capture Register 1 on page 26-711
0x0006 CAPT2—Capture Register 2 on page 26-712
0x0008 LOAD—Load Register on page 26-712
0x000A HOLD—Hold Register on page 26-713
0x000C CNTR—Counter Register on page 26-713
0x000E CTRL1—Control Register 1 on page 26-714
0x0010 CTRL2—Control Register 2 on page 26-716
0x0012 CTRL3—Control Register 3 on page 26-718
0x0014 STS—Status Register on page 26-719
0x0016 INTDMA—Interrupt and DMA Enable Register on page 26-721
0x0018 CMPLD1—Comparator Load Register 1 on page 26-722
0x001A CMPLD2—Comparator Load Register 2 on page 26-722
0x001C CCCTRL—Compare and Capture Control Register on page 26-723
0x001E FILT—Input Filter Register on page 26-725
eTimer Channel 1
0x0020 COMP1—Compare Register 1 on page 26-710
0x0022 COMP2—Compare Register 2 on page 26-711
0x0024 CAPT1—Capture Register 1 on page 26-711
0x0026 CAPT2—Capture Register 2 on page 26-712
0x0028 LOAD—Load Register on page 26-712
0x002A HOLD—Hold Register on page 26-713
0x002C CNTR—Counter Register on page 26-713
0x002E CTRL1—Control Register 1 on page 26-714
0x0030 CTRL2—Control Register 2 on page 26-716
0x0032 CTRL3—Control Register 3 on page 26-718
0x0034 STS—Status Register on page 26-719
0x0036 INTDMA—Interrupt and DMA Enable Register on page 26-721
0x0038 CMPLD1—Comparator Load Register 1 on page 26-722
0x003A CMPLD2—Comparator Load Register 2 on page 26-722
0x003C CCCTRL—Compare and Capture Control Register on page 26-723
