RM0046 Cross Triggering Unit (CTU)

Doc ID 16912 Rev 5 633/936

24.8.12 FIFO control register (FCR)

Figure 321. FIFO control register (FCR)

Address:

Base + 0x0070 Access: User read/write

0123456789101112131415

R00000000 00000 000

Reset0000000000000000

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

OR_EN3

OF_EN3

EMPTY_EN3

FULL_EN3

OR_EN2

OF_EN2

EMPTY_EN2

FULL_EN2

OR_EN1

OF_EN1

EMPTY_EN1

FULL_EN1

OR_EN0

OF_EN0

EMPTY_EN0

FULL_EN0

Reset0000000000000000

Table 329. FCR field descriptions

Field Description

OR_EN3

FIFO 3 Overrun interrupt enable

0Disabled

1 Enabled

OF_EN3

FIFO 3 threshold Overflow interrupt enable

0Disabled

1 Enabled

EMPTY_EN3

FIFO 3 Empty interrupt enable

0Disabled

1 Enabled

FULL_EN3

FIFO 3 Full interrupt enable

0Disabled

1 Enabled

OR_EN2

FIFO 2 Overrun interrupt enable

0Disabled

1 Enabled

OF_EN2

FIFO 2 threshold Overflow interrupt enable

0Disabled

1 Enabled

EMPTY_EN2

FIFO 2 Empty interrupt enable

0Disabled

1 Enabled

FULL_EN2

FIFO 2 Full interrupt enable

0Disabled

1 Enabled

OR_EN1

FIFO 1 Overrun interrupt enable

0Disabled

1 Enabled
