ST SPC560P34 - Table 132. REAT Field Descriptions; Figure 141. RAM ECC Attributes (REAT) Register

RM0046 Error Correction Status Module (ECSM)
Doc ID 16912 Rev 5 305/936
RAM ECC Data Register (REDR)
The REDR is a -bit register for capturing the data associated with the last properly enabled
ECC event in the RAM memory. Depending on the state of the ECC Configuration Register,
an ECC event in the RAM causes the address, attributes and data associated with the
access to be loaded into the REAR, RESR, REMR, REAT and REDR registers, and the
appropriate flag (R1BC or RNCE) in the ECC Status Register to be asserted.
The data captured on a multi-bit non-correctable ECC error is undefined.
This register can only be read from the IPS programming model; any attempted write is
ignored.
Figure 141. RAM ECC Attributes (REAT) register
Address: Base + 0x0067 Access: User read/write
01234567
R WRITE SIZE[2:0] PROTECTION[3:0]
W
Reset————————
Table 132. REAT field descriptions
Name Description
0
WRITE
AMBA-AHB HWRITE
0 AMBA-AHB read access
1 AMBA-AHB write access
1-3
SIZE[2:0]
AMBA-AHB HSIZE[2:0]
000 8-bit AMBA-AHB access
001 16-bit AMBA-AHB access
010 32-bit AMBA-AHB access
1xx Reserved
4
PROTECTION[3]
AMBA-AHB HPROT[3]
Protection[0]: Type
0 I-Fetch
1 Data
5
PROTECTION[2]
AMBA-AHB HPROT[2]
Protection[1]: Mode
0 User mode
1 Supervisor mode
6
PROTECTION[1]
AMBA-AHB HPROT[1]
Protection[2]: Bufferable
0 Non-bufferable
1Bufferable
7
PROTECTION[0]
AMBA-AHB HPROT[0]
Protection[3]: Cacheable
0 Non-cacheable
1 Cacheable
