Interrupt Controller (INTC) RM0046
218/936 Doc ID 16912 Rev 5
INTC Priority Select Registers (INTC_PSR0_3–INTC_PSR220_221)
Figure 84. INTC Priority Select Register 0–3 (INTC_PSR[0:3])
Address Base + 0x0040 Access: User read/write
0123456789101112131415
R0000
PRI0
0000
PRI1
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R0000
PRI2
0000
PRI3
W
Reset0000000000000000
Figure 85. INTC Priority Select Register 220–221 (INTC_PSR[220:221])
Address Base + 0x011C Access: User read/write
0123456789101112131415
R0000
PRI220
0000
PRI221
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 0 000000000000000
W
Reset0000000000000000
Table 73. INTC_PSR0_3–INTC_PSR220–221 field descriptions
Field Description
4–7, 12–15, 20–
23, 28–31
PRI[0:3]–
PRI220:221
Priority Select
PRIx selects the priority for interrupt requests. Refer to Section 9.6, “Functional description.
Table 74. INTC Priority Select Register address offsets
INTC_PSRx_x Offset Address INTC_PSRx_x Offset Address
INTC_PSR0_3 0x0040 INTC_PSR112_115 0x00B0
INTC_PSR4_7 0x0044 INTC_PSR116_119 0x00B4
INTC_PSR8_11 0x0048 INTC_PSR120_123 0x00B8
INTC_PSR12_15 0x004C INTC_PSR124_127 0x00BC
INTC_PSR16_19 0x0050 INTC_PSR128_131 0x00C0
INTC_PSR20_23 0x0054 INTC_PSR132_135 0x00C4
INTC_PSR24_27 0x0058 INTC_PSR136_139 0x00C8
