RM0046 Cross Triggering Unit (CTU)
Doc ID 16912 Rev 5 625/936
24.8.4 TGS Counter Compare Register (TGSCCR)
24.8.5 TGS Counter Reload Register (TGSCRR)
Table 319. TxCR field descriptions
Field Description
TxCRV Trigger x Compare Register Value
Figure 312. TGS Counter Compare Register (TGSCCR)
Address: Base + 0x0016 Access: User read/write
0123456789101112131415
R
TGSCCV
W
Reset0000000000000000
Table 320. TGSCCR field format
Field Description
TGSCCV TGS Counter Compare Value
Figure 313. TGS Counter Reload Register (TGSCRR)
Address: Base + 0x0018 Access: User read/write
0123456789101112131415
R
TGSCRV
W
Reset0000000000000000
Table 321. TGSCRR field descriptions
Field Description
TGSCRV TGS Counter Reload Value
