RM0046 LIN Controller (LINFlex)
Doc ID 16912 Rev 5 513/936
Identifier filter enable register (IFER)
Table 253. BDRM field descriptions
Field Description
DATA7
Data Byte 7
Data byte 7 of the data field.
DATA6
Data Byte 6
Data byte 6 of the data field.
DATA5
Data Byte 5
Data byte 5 of the data field.
DATA4
Data Byte 4
Data byte 4 of the data field.
Figure 251. Identifier filter enable register (IFER)
Offset: 0x0040 Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
FACT
W
Reset0000000000000000
Table 254. IFER field descriptions
Field Description
FACT
Filter activation
The software sets the bit FACT[x] to activate the filters x in identifier list mode.
In identifier mask mode bits FACT(2n + 1) have no effect on the corresponding filters as they act
as masks for the Identifiers 2n.
0 Filter x is deactivated.
1 Filter x is activated.
This field can be set/cleared in Initialization mode only.
