Boot Assist Module (BAM) RM0046
808/936 Doc ID 16912 Rev 5
Boot configuration pins are:
● PAD A[2] - ABS[0],
● PAD A[3] - ABS[1],
● PA D A [ 4 ] - FA B
Note: PAD A[2] - ABS[0] is not bonded on SPC560P40/34 64-pin LQFP package so for this
package the option 'FlexCAN without Autobaud ' is not available and the internal pull-down
on PAD A[2] assures that it is at low logical value at reset.
33.5.2 SPC560P40/34 boot pins
The TX/RX pin (LINFlex_0 and FlexCAN_0) used for serial boot and configuration boot pins
to select the serial boot mode are described in the Ta ble 4 3 6 for 64-pin and 100-pin LQFP
packages.
Table 435. Hardware configuration to select boot mode
FAB ABS[1:0]
(1)
Standby-RAM
Boot Flag
Boot ID Boot Mode
1 00 0 — LINFlex without autobaud
1 01 0 — FlexCAN without autobaud
1 10 0 — Autobaud scan
1. During reset the boot configuration pins are weak pull down.
Table 436. SPC560P40/34 boot pins
Port pin Function
Pin
64-pin 100-pin
A[2]
(1)
ABS[0] — 57
A[3]
1
ABS[1] 41 64
A[4]
1
FAB 48 75
B[0] CAN_0 TX 49 76
B[1] CAN_0 RX 50 77
B[2] LIN_0 TX 51 79
B[3]
(2)
LIN_0 RX — 80
(2)
B[7]
(3)
CAN_0 RX 20
(3)
29
1. Weak pull down during reset.
2. SPC560P40/34 100-pin LQFP package uses only PAD B[3] - pin 80 for boot via LINFLEX.
3. SPC560P40/34 64-pin LQFP package uses only PAD B[7] - pin 20 for boot via LINFLEX.
