RM0046 Cross Triggering Unit (CTU)
Doc ID 16912 Rev 5 627/936
24.8.8 Trigger handler control register 1 (THCR1)
Figure 316. Trigger handler control register 1 (THCR1)
Address: Base + 0x0024 Access: User read/write
0123456789101112131415
R000
T3_E
T3_
ETE
T3_
T1E
T3_
T0E
T3_
ADCE
000
T2_E
T2_
ETE
T2_
T1E
T2_
T0E
T2_
ADCE
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R000
T1_E
T1_
ETE
T1_
T1E
T1_
T0E
T1_
ADCE
000
T0_E
T0_
ETE
T0_
T1E
T0_
T0E
T0_
ADCE
W
Reset0000000000000000
Table 324. THCR1 field descriptions
Field Description
T3_E
Trigger 3 enable
0 Disabled
1Enabled
T3_ETE
Trigger 3 External Trigger output enable
0 Disabled
1Enabled
T3_T1E
Trigger 3 Timer 1 output enable
0 Disabled
1Enabled
T3_T0E
Trigger 3 Timer 0 output enable
0 Disabled
1Enabled
T3_ADCE
Trigger 3 ADC command output enable
0 Disabled
1Enabled
T2_E
Trigger 2 enable
0 Disabled
1Enabled
T2_ETE
Trigger 2 External Trigger output enable
0 Disabled
1Enabled
T2_T1E
Trigger 2 Timer 1 output enable
0 Disabled
1Enabled
T2_T0E
Trigger 2 Timer 0 output enable
0 Disabled
1Enabled
