ST SPC560P34 - Figure 309. Trigger Generator Sub-Unit Input Selection Register (TGSISR); Table 316. FIFO Registers

RM0046 Cross Triggering Unit (CTU)
Doc ID 16912 Rev 5 621/936
24.8.1 Trigger Generator Sub-unit Input Selection Register (TGSISR)
0x00CA CTUDF — Cross Triggering Unit Digital Filter Yes DFE 0x0000
0x00CC
CTUPCR — Cross Triggering Unit Power Control
Register
No — 0x0000
Table 315. CTU registers (continued)
Offset from
CTU_BASE
Register
Double-
buffered
Synchronization
Reset
value
Table 316. FIFO registers
Offset from
CTU_BASE
Register
Double-
buffered
Synchronization Reset value
0x006C FDCR — FIFO DMA Control Register No — 0x0000
0x0070 FCR — FIFO Control Register No — 0x0000_0000
0x0074 FTH — FIFO Threshold Register No — 0x0000_0000
0x007C FST — FIFO Status Register No — 0x0000_0000
0x0080 FR0 — FIFO Right aligned data 0 No — 0x0000_0000
0x0084 FR1 — FIFO Right aligned data 1 No — 0x0000_0000
0x0088 FR2 — FIFO Right aligned data 2 No — 0x0000_0000
0x008C FR3 — FIFO Right aligned data 3 No — 0x0000_0000
0x00A0 FL0 — FIFO Left aligned data 0 No — 0x0000_0000
0x00A4 FL1 — FIFO Left aligned data 1 No — 0x0000_0000
0x00A8 FL2 — FIFO Left aligned data 2 No — 0x0000_0000
0x00AC FL3 — FIFO Left aligned data 3 No — 0x0000_0000
Figure 309. Trigger Generator Sub-unit Input Selection Register (TGSISR)
Address: Base + 0x0000 Access: User read/write
0123456789101112131415
R
I15_
FE
I15_
RE
00
I13_
FE
I13_
RE
I12_
FE
I12_
RE
I11_
FE
I11_
RE
I10_
FE
I10_
RE
I9_
FE
I9_
RE
I8_
FE
I8_
RE
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
I7_
FE
I7_
RE
I6_
FE
I6_
RE
I5_
FE
I5_
RE
I4_
FE
I4_
RE
I3_
FE
I3_
RE
I2_
FE
I2_
RE
I1_
FE
I1_
RE
I0_
FE
I0_
RE
W
Reset0000000000000000
