LIN Controller (LINFlex) RM0046
506/936 Doc ID 16912 Rev 5
LIN output compare register (LINOCR)
LIN timeout control register (LINTOCR)
Figure 242. LIN output compare register (LINOCR)
Offset: 0x001C Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
OC2
1
OC1
1
W
Reset1111111111111111
1. If LINTCSR[LTOM] = 0, this field is read-only.
Table 244. LINOCR field descriptions
Field Description
OC2
Output compare 2 value
These bits contain the value to be compared to the value of bits CNT[0:7] in LINTCSR.
OC1
Output compare 1 value
These bits contain the value to be compared to the value of bits CNT[0:7] in LINTCSR.
Figure 243. LIN timeout control register (LINTOCR)
Offset: 0x0020 Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 0000
RTO
0
HTO
W
Reset0000111000101100
