RM0046 Deserial Serial Peripheral Interface (DSPI)
Doc ID 16912 Rev 5 463/936
Figure 217. DSPI start and stop state diagram
The transitions are described in Table 221.
State transitions from RUNNING to STOPPED occur on the next frame boundary if a
transfer is in progress, or on the next system clock cycle if no transfers are in progress.
20.8.3 Serial Peripheral Interface (SPI) configuration
The SPI configuration transfers data serially using a shift register and a selection of
programmable transfer attributes. The DSPI is in SPI configuration when the DCONF field in
the DSPIx_MCR is 0b00. The SPI frames can be from 4 to 16 bits long. The data to be
transmitted can come from queues stored in RAM external to the DSPI. Host software or an
eDMA controller can transfer the SPI data from the queues to a first-in first-out (FIFO) buffer.
The received data is stored in entries in the receive FIFO (RX FIFO) buffer. Host software or
an eDMA controller transfers the received data from the RX FIFO to memory external to the
DSPI.
The FIFO buffer operations are described in Section , “Transmit First In First Out (TX FIFO)
buffering mechanism and Section , “Receive First In First Out (RX FIFO) buffering
mechanism.”
The interrupt and DMA request conditions are described in Section 20.8.7, “Interrupts/DMA
requests.”
RUNNING
TXRXS = 1
STOPPED
TXRXS = 0
RESET
Power-on-Reset 0
1
2
Table 221. State transitions for start and stop of DSPI transfers
Transition # Current State Next State Description
0 RESET STOPPED Generic power-on-reset transition
1 STOPPED RUNNING
The DSPI starts (transitions from STOPPED to RUNNING) when
all of the following conditions are true:
– EOQF bit is clear
– Debug mode is unselected or the FRZ bit is clear
– HALT bit is clear
2 RUNNING STOPPED
The DSPI stops (transitions from RUNNING to STOPPED) after
the current frame for any one of the following conditions:
– EOQF bit is set
– Debug mode is selected and the FRZ bit is set
– HALT bit is set
